铜铝复合散热器也称铜铝复合暖气片，是一种把铜管与铝翼型材用精密涨压工艺做成的供暖系统末端散热元件，走水部分为紫铜管，散热部分为合金铝，是根据市场的发展需求暖气片铜铝复合，近年来研发生产较多的的一种高效节能散热器，其外观可以多种多样，可以满足不同消费者的消费理念。
散热器 | 散热面积(M2) | 通风净 | 热 | 管 | 受热 | 热介质 | 尺寸：mm | 连 | 重量(Kg) | ||||||||
A | B | A1 | B1 | A2 | B2 | A3 | B3 | C | |||||||||
SRL-5×5/3 | 16.7 | 0.11 |
| 35 | 0.88 | 0.0070 | 500 | 400 | 545 | 500 | 540 | 570 | 200 | 11/2" | 51 | ||
SRL-5×5/2 | 11.0 | 0.11 | 23 | 0.58 | 0.0046 | 160 | 38 | ||||||||||
SRL-10×5/3 | 34.0 | 0.22 | 35 | 1.76 | 0.0070 | 900 | 1000 | 575 | 1040 | 605 | 1070 | 200 | 83 | ||||
SRL-10×5/2 | 22.3 | 0.22 | 23 | 1.16 | 0.0046 | 160 | 50 | ||||||||||
SRL-12×5/3 | 42.6 | 0.27 | 35 | 2.20 | 0.0082 | 1200 | 1250 |
| 1290 |
| 1320 | 200 | 99 | ||||
SRL-12×5/2 | 28.0 | 0.27 | 23 | 1.45 | 0.0054 | 160 | 71 | ||||||||||
SRL-6×6/3 | 23.6 | 0.15 | 41 | 1.24 | 0.0082 | 200 | 11/2" | 66 | |||||||||
SRL-6×6/2 | 15.6 | 0.15 | 27 | 0.82 | 0.0054 | 500 | 600 | 640 | 670 | 160 | 43 | ||||||
SRL-10×6/3 | 39.8 | 0.26 | 41 | 2.06 | 0.0082 |
|
|
|
| 200 | 95 | ||||||
SRL-10×6/2 | 26.2 | 0.26 | 27 | 1.36 | 0.0054 | 900 | 1000 | 1040 | 1070 | 160 | 49 | ||||||
SRL-12×6/3 | 49.9 | 0.32 | 41 | 2.58 | 0.0082 | 600 | 1200 | 635 | 1250 | 665 | 1290 | 695 | 1320 | 200 | 113 | ||
SRL-12×6/2 | 32.9 | 0.32 | 27 | 1.70 | 0.0054 | 160 | 81 | ||||||||||
SRL-15×6/3 | 60.0 | 0.39 | 41 | 3.09 | 0.0082 | 200 | 131 | ||||||||||
SRL-15×6/2 | 39.5 | 0.39 | 27 | 2.04 | 0.0054 | 1400 | 1500 | 1540 | 1570 | 160 | 94 | ||||||
SRL-24×6/3 | 95.8 | 0.60 | 41 | 4.89 | 0.0082 |
|
|
|
| 200 | 197 | ||||||
SRL-24×6/2 | 63.1 | 0.60 | 27 | 3.23 | 0.0054 | 2300 | 2400 | 2440 | 2470 | 160 | 138 | ||||||
SRL-7×7/3 | 31.0 | 0.21 |
| 47 | 1.65 | 0.0094 |
|
|
|
|
|
|
|
| 200 | 2" | 83 |
SRL-7×7/2 | 20.9 | 0.21 | 31 | 1.09 | 0.0062 |
| 600 |
| 700 |
| 740 |
| 770 | 160 | 60 | ||
SRL-10×7/3 | 45.? | 0.30 | 47 | 2.36 | 0.0094 |
|
|
|
|
|
|
|
| 200 | 107 | ||
SRL-10×7/2 | 31.0 | 0.30 | 31 | 1.56 | 0.0062 |
| 900 |
| 1000 |
| 1040 |
| 1070 | 160 | 77 | ||
SRL-12×7/3 | 57.2 | 0.37 | 47 | 2.96 | 0.0094 |
|
|
|
|
|
|
|
| 200 | 127 | ||
SRL-12×7/2 | 37.8 | 0.37 | 31 | 1.95 | 0.0062 |
| 1200 |
| 1250 |
| 1290 |
| 1320 | 160 | 91 | ||
SRL-14×7/3 | 66.1 | 0.43 | 47 | 3.41 | 0.0094 |
|
|
|
| 200 | 144 | ||||||
SRL-14×7/2 | 43.6 | 0.43 | 31 | 2.25 | 0.0062 | 700 | 1400 | 725 | 1450 | 755 | 1490 | 785 | 1250 | 160 | 102 | ||
SRL-15×7/3 | 68.8 | 0.45 | 47 | 3.54 | 0。0094 |
|
|
|
|
|
|
|
| 200 | 148 | ||
SRL-15×7/2 | 45.4 | 0.45 | 31 | 2.34 | 0.0062 |
| 1400 |
| 1500 |
| 1540 |
| 1570 | 160 | 105 | ||
SRL-17×7/3 | 80.4 | 0.50 | 47 | 4.13 | 0.0094 |
| 1700 |
| 1750 |
| 1790 |
| 1820 | 200 | 169 | ||
SRL-17×7/2 | 53.1 | 0.50 | 31 | 2.73 | 0.0062 |
|
|
|
| 160 | 120 | ||||||
SRL-22×7/3 | 101.3 | 0.66 | 47 | 5.21 | 0.0094 |
| 2100 |
| 2200 |
| 2240 |
| 2270 | 200 | 196 | ||
SRL-22×7/2 | 66.8 | 0.66 | 31 | 3.43 | 0.0062 | 160 | 145 | ||||||||||
SRL-15×10/3 | 95.2 | 0.69 |
| 65 | 4.91 | 0.0130 | 100 | 1400 |
995
| 1500 | 1025 | 1540 | 1055 | 1570 | 200 | 21/2" | 215 |
SRL-15×10/2 | 63.0 | 0.69 | 43 | 3.25 | 0.0086 | 160 | 140 | ||||||||||
SRL-17×10/3 | 111.4 | 0.74 | 65 | 5.72 | 0.0130 | 1700 | 1750 | 1790 | 1320 | 200 | 226 | ||||||
SRL-17×10/2 | 73.6 | 0.74 | 43 | 3.89 | 0.0086 | 160 | 159 | ||||||||||
SRL-20×10/3 | 127.5 | 0.85 | 65 | 6.54 | 0.0130 | 1900 | 2000 | 2040 | 2070 | 200 | 252 | ||||||
SRL-20×10/2 | 84.2 | 0.85 | 43 | 4.33 | 0.0086 | 160 | 177 | ||||||||||
SRL-14×8/2 | 50.7 | 0.54 | 35 | 2.55 | 0.0070 | 800 | 1400 | 815 | 1450 | 845 | 1490 | 875 | 1520 | 160 | 2" | 108 | |
